Raymarine i60 Wind Instrument Displays

The i60 instruments are designed to complement the all new Raymarine multifunctional displays. Designed specifically for sailboaters, these stylish, dedicated-function instruments cover wind and close-hauled wind options in analogue and digital formats. The excellent viewing angles for both day and night conditions and simple, push-button controls make i60 instruments extremely easy to see and use. They are also simple to install thanks to the front mount design.

Choose from two i60 Wind Instrument Displays:

i60 Wind

Displays both analogue and digital data. The i60 Wind calculates apparent (relative) and true wind speed/angle (true wind requires SeaTalk speed through water data).

i60 Close Hauled Wind

With a magnified 20°-60° display, the i60 Close Hauled Wind is the perfect instrument when a single degree makes all the difference.

Raymarine i60 Instrument Display features

• Large numerals and digits
• Red back lighting for enhanced night time visibility
• SeaTalk and SeaTalkng interfaces
• NMEA2000 (compatible) interface
• Built-in transducer interface
• 110mm x 115mm footprint identical to older Raymarine ST60+ instrumentation
• Low power consumption
• Multiple data source support eliminates potential data conflicts
• Front mounted design for simple installation

TECHNICAL DETAILS

MODEL	RAYMARINE i60
Dimensions
Nominal voltage	12V DC
Operating voltage range	10 - 16V DC
Power consumption	typically <1W (display only) and 2.4W maximum with transducer connected
Current consumption	45 to 65mA (display only) and 200mA maximum with transducer connected
Operating temperature range	-20ºC to +55ºC
Storage temperature	-30ºC to +70ºC
Relative humidity	up to 93%
Waterproofing standard	IPX6
Connections	2 x SeaTalkng and transducers   Compatible with marine industry CAN systems
Conformance	Europe 2004/108/EC
